Description
Training project
- Industrial touch screen programming
- Siemens S7-300 programmable controller (PLC) programming;
- All-digital DC speed regulator (6RA70 series) parameter setting, basic control training;
- Motor no-load (EMF control mode) speed setting fixed value debugging training;
- Motor no-load (EMF control mode) speed setting actual value debugging training;
- Full digital DC speed regulator (6RA70 series) open loop speed regulation training;
- Full digital DC speed regulator (6RA70 series) current loop (inner loop) speed regulation training;
- All-digital DC speed regulator (6RA70 series) speed loop (outer loop) speed control training;
- Full digital DC speed controller (6RA70 series) double closed loop speed control training;
- Full digital DC speed regulator (6RA70 series) non-independent field weakening control training;
- RS232 communication training between PC and all-digital DC speed controller (6RA70 series);
- Siemens G120C inverter parameter setting, basic control training;
- Use Siemens G120C frequency converter to adjust the motor speed;
- Inverter G120C makes the motor start at a fixed frequency;
- Inverter G120C adjusts the speed of the motor through the speed regulating potentiometer;
- Inverter G120C adjusts the speed through the digital input terminal;
- Inverter G120C sets fixed frequency through digital input terminal;
- WinCC industrial control configuration software programming;
- Stand-alone control based on USS communication mode;
- Parameter monitoring training of touch screen and inverter G120C;
- Speed control system composed of PLC and DC speed regulator based on PROFIBUS-DP communication mode;
- Speed control system composed of PLC, touch screen and DC speed controller based on PROFIBUS-DP communication mode;
- The speed control system of PLC and inverter G120C based on PROFIBUS-DP communication mode;
- Practical training based on PROFIBUS-DP communication method such as PLC, touch screen, and inverter G120C speed control system.
